Arduino Nano

Arduino Nano – Compact Yet Powerful Microcontroller Board

The Arduino Nano is a small, breadboard-friendly microcontroller board designed for ease of use and versatility in compact electronics projects. Powered by the ATmega328P microcontroller, it offers the same core functionality as the Arduino Uno but in a much smaller form factor.

Key Features:

• Microcontroller: ATmega328P

• Operating Voltage: 5V

• Input Voltage (recommended): 7-12V

• Digital I/O Pins: 14 (6 PWM outputs)

• Analog Input Pins: 8

• Flash Memory: 32 KB (of which 2 KB used by bootloader)

• SRAM: 2 KB

• EEPROM: 1 KB

• Clock Speed: 16 MHz

• USB Interface: Mini USB

Highlights:

• Perfect for prototyping on breadboards due to its compact size

• Easily programmable via USB using the Arduino IDE

• Ideal for wearables, robotics, sensors, and IoT applications

• Low power consumption and fast performance

Whether you’re building your first project or developing a complex embedded system, the Arduino Nano is a reliable and space-saving choice for makers and developers alike.
